Water Cooling Chiller

Cooling Chiller features:


1) Good shape with small outside size, light weight
2) Optimum structure
3) The cooling tower body is made of FRP, which is anti-aging, anti-corrosion, without fading and distortion
4) Min. Noise: The lowest noise blower and unique noise elimination technology is adopted to reduce the noise to a minimum level
5) with reliable operation: All steel structure brackets are galvanized and corrosion resistant. The usage life is twice longer compared with similar products
6) Simple operation and maintenance: CTNC intelligent control system is adopted to realize labor free management
7) The angles of all the fans are regulative and axial-flow, which are made of advanced engineering plastics.
8) All the motors are sealed, which can be used in the severe weather and circumstances.

 9) The casing and water plate of the cooling tower are made of fiberglass, which will not be corroded, and no painting is needed. They can be used for a long time with very low maintenance cost.

10) The radiating film is made of polyvinyl chloride hard and heat-resisting.
The temperature in the water is up to 54. C and the special structure enables the water to touch the film in the biggest area with low air resistance. The energy exchanging efficiency is very high.

Technical Parameters:

Model AC-0.6 AC-1 AC-2 AC-3 AC-5 AC-6 AC-8(D) AC-10(D) AC-12 AC-15(D) AC-20(D) AC-25(D) AC-30(D)
nominal cooling apacity Kcal/h
50HZ/60HZ
1290 2382 4541 6803 11094 13091 17604 22188 25146 35500 44230 50293 68043
1514 2786 5315 7955 13235 15901 21001 26478 29661 41882 52064 59314 81648
Btu/h
50HZ/60HZ
5119 9452 18019 26994 44021 51937 69853 88042 99779 140864 175505 199563 269995
6008 11055 21090 31565 52516 63095 83332 105065 117695 166188 206590 235358 323979
KW
50HZ/60HZ
1.5 2.77 5.28 7.91 12.9 15.22 20.47 25.8 29.24 41.28 51.43 58.48 79.12
1.76 3.24 6.18 9.25 15.39 18.49 24.42 30.79 34.49 48.7 60.54 68.97 94.94
US.RT/h
50HZ/60HZ
0.43 0.79 1.51 2.25 3.67 4.33 5.83 7.34 8.32 11.74 14.63 16.64 22.5
0.5 0.93 1.76 2.63 4.38 5.26 6.95 8.76 9.81 13.85 17.22 19.62 27
input power KW 1.01 1.34 2.27 3.33 5.8 6.33 9.25 10.37 11.58 15.82 21 23.8 33.2
power supply 1PH~220V 50HZ(60HZ) 3PH~380V 50HZ(60HZ)
refrigerant type R22(R134a/R407c)
  type of contol capillary thermostatic expansion valve
compressor type hermetic rotary hermetic scroll(piston)
  power(KW) 0.59 0.89 1.77 2.8 4.66 5.2 3.8*2 4.66*2 9.98 7.2*2 8.85*2 9.98*2 13.62*2
condenser type finned copper tube + low noise outer rotor fan
  cooling air flow(m3/h) 750 1000 2000 3000 5000 6000 8000 10000 12000 15000 20000 25000 30000
evaporator type water tank with coil (shell and tube)
chilled fluid flow(m3/h) 0.258 0.476 0.908 1.36 2.22 2.6 3.52 4.44 5.03 7.1 8.84 10.06 13.6
0.303 0.557 1.063 1.59 2.65 3.2 4.2 5.3 5.93 8.37 10.41 11.86 16.33
tank volume(L) 16 20 40 50 70 70 120 200 200 270 350 350 420
inlet and outlet pipe diameter 1/2" 1/2" 1/2" 1" 1" 1" 1" 1-1/2" 1-1/2" 2" 2" 2-1/2" 2-1/2"
water pump power(KW) 0.37 0.37 0.37 0.37 0.75 0.75 0.75 0.75 1.1 1.5 2.25 2.25 3.75
  lift(m) 20 20 20 20 20 20 22 20 20 20 20 20 22
safety protection compressor over temperature, over current, high and low pressure, over temperature, flow switch, phase sequence, phase-missing, exhaust overheating,antifreezing
dimensions length(mm) 500 500 580 930 1140 1140 1300 1530 1680 1800 2000 2000 2200
width(mm) 500 500 550 520 560 560 720 780 810 990 1130 1130 1130
height(mm) 725 725 925 975 1040 1040 1350 1470 1280 1680 1720 1914 2100
weight kg 50 73 100 135 175 180 320 450 530 750 835 920 1080

Note:1.nominal cooling capacity is   according to:
       Inlet chilled fluid temperature:12°C,
       Outlet chilled fluid temerature:7°C,
       Inlet cooling air temperature:30°C
       Outlet cooling air temperature:38°C.
  2.working range:
  The temerature range of chilled fluid is from 5°C to 5°C,
  Temperature difference between inlet and outlet chilled fluid is from  3°C to 8°C,
  It is better to use the chiller while the ambient temerature at or below 35°C
